Product Feature
1.Linear guide rails and German automatic anti-backlash double-nut ball screw ensure the high precision and perfect effect of metal engraving .
2.High-speed driver faster the speed by nearly two meters.
3 Supporting with the international standard G code command is compatible with different engraving softwar at home and abroad.
4. Breakpoint memory and save method of 9 processed points at most engsures the continuity and convenience of work.
5.Axis adopts the popular dustproof which ensures the good performance for long time.
Model |
SK6090 |
Optional |
||
Working area(X, Y,Z mm) |
600*900*80 |
Customization available |
||
Machine structure |
All cast aluminum |
|
||
Working holding |
By clamps |
|
||
Overall dimension (mm) |
1300*950*1150 |
|
||
Precision(mm) |
0.05 |
|
||
Positioning accuracy(mm) |
0.02 |
|
||
Idling speed(mm/min) |
5000 |
|
||
Working speed (mm/min) |
3000 |
|
||
Spindle |
1.5kw water cooling
|
Customization available |
||
Rotating speed |
0-24000rpm |
ATC is ok |
||
Available Tools |
Diameter 3.175-6mm |
|
||
Drive system |
Stepper motor |
Servo motor |
||
Working voltage |
AC220V±30V,50HZ |
|
||
Command code |
G code |
|
||
Compatible software |
Compatible with any softare generating G code file in Windows 98/XP/7 |
|
||
Other optionals |
||||
Dust collection |
Tool cooling system with sink |
Rotary device |
