Product Features:
1) Double-nut ball screws from German offer high working accuracy.
2) Restoring function enable the machine continue to work after sudden stop, such as accident tool breaking.
3) Sample made out is not only delicate without serrature, the bottom is also is smooth and in thigh edge sharpness.
4) Square guide on axis Y is optional for high accuracy request in large size material.
Technical Parameter
|
Model |
SK-1224 |
Optional parts |
|
Working area(X,Y,Z,mm) |
1200*2400*120 |
Customization is available |
|
Machine structure |
Steel structure lathe bed |
Vacuum table |
|
Working holding |
By clamps |
|
|
Overall dimensions(mm) |
1650*2950*1250 |
|
|
Precision (mm) |
0.07 |
|
|
Positioning accuracy(mm) |
0.02 |
|
|
Repeatability(mm) |
0.02 |
|
|
Idling speed(mm/min) |
6000 |
|
|
Working speed(mm/min) |
4,500 |
|
|
Spindle |
1.5kw water cooling (0-24000rpm) |
Specified power, air cooling (0-18000rpm) multi-head |
|
Available tools(mm) |
Φ3.175-6 |
Automatic tool changer |
|
Drive system |
Stepper motor |
Servo motor |
|
Working voltage |
AC220±30V/ 50H |
|
|
Command code |
G code(*nc*mng,*u00,etc) |
|
|
Control system |
Ncstudio system |
DSP hand-held |
|
Compatible software |
Compatible with any software generating G code file in Windows98/XP/7 |
|
|
Other Optional parts |
||
|
Dust collection |
Tool cooling system with sink |
Rotary axis |
