Protect features:
1.Whole lathe bed is in stel structure of high stability.
2.Racks and gears transmission with high-speed motor keeps smooth movement in fast and accuracy.
3.Breakpoint restoring function enable the machine contiune to work after sudden stop,such as accident,tool breaking,
4.Wide software compatibility with processing files generated by Types3,ArtCAM,Artcut,AutoCAD,JDPaint etc.CAD/CAM design software
5.Auto lubrication system lubricating tracks automatically ensures machine's precision and services time.
Standard Configuration:
|
Standard Configurations |
Options |
|
Square Tube Lathe Bed, absorption table-board |
2.2kw Dust Collector |
|
X Y with racks, all with square guides |
|
|
Axis Y with two motors |
|
|
DSP System |
|
|
4.5 W Spindle and Transducer |
|
|
Large Leadshine driver |
|
|
5.5 KW High-power Vacuum Pump |
|
|
Auto Lubrication System |
|
|
Max. Speed 30-40m/min |
|
Technical Parameters:
|
Technical Data |
|
|
X Y Working Area |
1200mm1200mm*200mm |
|
Z Working Area |
>200mm |
|
Max. Operation Speed |
24000mm/min |
|
Clamping |
Vacuum Absorption |
|
Processor |
DSP/ Speed 100MHZ |
|
Interface |
USB |
|
Command Code |
G Code*.u00*.mmg*.plt |
|
Working Software |
DSP |
|
Power (not including spindle) |
1500-2000w |
|
Working Voltage |
380V/50HZ |
|
Spindle Power |
4.5kw |
|
Spindle Running Speed |
18000-24000rpm |
|
Motor |
Stepper |
