Main Features:
1.Genuine EzCad software.
2.Raycus Fiber laser source offer 3 years Warranty.
3.High quality laser beam. The diameter of focal spot not over 20μm.
4.High speed marking. Special laser head for High-speed scanning.
5.Low consumption.
6.Long lifetime without maintenance. More than 100000 working life.
7.Small size suit for harsh working environment.
8.Fast processing speed. High precision.
Applicable Industries
Electronic Components: Resistors, Capacitors, Chips, Printed Circuit Boards, Keyboard, etc.
Mechanical Parts: Bearings, Gears, Standard Parts, Motor, etc.
Instrument: Panel Board, Nameplates, Precision equipment, etc.
Hardware Tools: Knives, Tools, Measuring Tools, Cutting Tools, etc.
Automobile Parts: Pistons&Rings,Gears,Shafts,Bearings,Clutch,Lights.
Daily Necessities: Handicrafts, Zipper, Key Holder, Sanitary Ware, etc.
|
Laser Type |
Fiber laser |
|
Laser Wavelength |
1064nm |
|
Laser Power |
20W/30W/50W/70W/100W |
|
Power Consumption |
500W~1000W(220VAC,50HZ) |
|
Marking Focal Length |
100mm~190mm |
|
Positioning Accuracy |
0.01mm |
|
Min Line Width |
0.1mm |
|
Marking Area |
50mm X 50mm~175mm X 175mm or other customized |
|
Marking Speed |
≤16000mm/s (according to different material) |
|
Character Size |
Adjustable in Marking Range |
|
Marking Line number |
Adjustable in Marking range |
|
Marking Content |
Chinese and English Character/Numbers/Graphics/Date and Time/Serial Number, etc |
|
Marking Font |
All kinds of standard CAD geometric font, also can be user-defined extended |
|
Galvanometer scanner |
Visjet/German Scanlab |
Sample Photo:
