Feature:
1. Heavy machine body structure
2.1300*2500mmor 1500*3000mm working area
3.LGK63Aplasma power supply
4. Starfire control system
5.high sensitive auto Arc pressure control
6.StarCAM software
7. High precision Square guide
8. High precision rack and pinion movement, 1.25mm teech
9.High precision step motor
10. Tool box with some consumable parts
11. 2G processing file
|
Model |
1325/ 1530 |
|
X,Y working area |
1300*2500mm/1500*3000mm |
|
Zworking area |
150mm |
|
Packing size |
2000mm*3400mm*1550mm |
|
Machine body design |
Heavy structure |
|
Total power |
8.5kw |
|
working voltage |
380V/50HZ three phase |
|
re-positioning precision |
0.02mm |
|
working precision |
0.1mm |
|
Max cutting speed |
8000mm/min |
|
Auto height controller |
high sensitive auto Arc pressure control |
|
Plasma power supply |
Huayuan 63A |
|
cutting thickness |
Carbon steel max 12mm，stainless steel max 6mm |
|
control system |
Star Fire |
|
Motor |
high precision step motor |
|
software |
StarCAM |
|
weight |
2150KG |
|
plasma air compressor |
Max0.8Mpa |
|
working temperature |
-10°C-60°C. relative humidity, 0-95%. |
|
LCD screen size |
7.0 inch |
