Key Feather
1.Equipped with Auto-feeding system enable the machine to cut soft materials in rolls automatically
2.Imported dual linear guide which enable the machine move stably and cut the edge smoothly
3.Adopt three-phase motor and driver, belt can move in fast cutting speed and high precision.
4.Advanced control system: Advanced DSP numerical control systm and laserge liquid crystal display brings out much convenient operation and simpler maintenance.Special intelligent pre-calculating system fully develops the potential of the engine and leads to high speed processing of smoother curves and straight lines simultaneously.
5.Powerful compatibility: Internationalized directives ensure that it is compatible with CAD/CAM software like type3/ artcam/ castmate/ proe/ UG/ artcut etc. home and abroad.
6. Off-line control system: Apply USB interface to communicate with computer under the systemof WIN98/NT2000/XP, which can instantly compete transmission.
Model |
Auto feeding Laser engraving machine SK1325 |
Working area |
1300*2500mm |
Laser tube power |
80w,100w,130w,150w(can be optional) |
laser stype |
Sealed CO2 laser tube, water-cooling, 10.6um |
Working life of tube |
1500hours/10000 hours for Reci |
Max Engraving speed |
0 - 60,000mm/min |
Cutting speed |
0- 30,000mm/min |
Location precison |
≤0.01mm |
Resetting positioning accuracy |
0.01mm |
Resolution ratio |
≤1000 dpi |
Laser tuber cooling |
Water cooling |
Power supply |
AC 110 - 220V , 50 - 60Hz |
Min. shaping character |
Chinese 2mm*2mm,English 1mm*1mm |
Supported graphic |
BMP, CDR, PLT, DST, DXF, and AI |
Driving system |
Stepper motor |
360° slope engrave |
Yes |
Cooling system |
Water-cooling and protection system |
Operating system |
Windows98/ME/2000/XP/VISTA/2007 |
Software supported |
CorelDraw, AutoCAD , Photo shop |
Operating temperature |
0°C~45°C |
Operating humidity |
5%~95% |
Gross power |
≤1000w |
Computer interface |
USB port and Standard printer port |
English manual |
Tell you how to run the laser machine and also the problems and solutions |
