1290

Service Hotline：+86-18668923691 Online Ordering

Presentation

Features:
1.Front and rear hole to pass long materials
2.Modern design and beautiful appearance
3.Use imported Taiwan Hiwin linear guide, more durable and high precision
4.Water protection switch ,safety switch and limit switch
5.Adopt DSP control system, and USB offline operation,LCD screen
6.Powerful production ability,can produce all kinds of laser machines, like double head laser , four head laser ,CCD camera laser,auto feeding fabric laser cutter,YAG metal laser engraver,separate marble laser etc.

parameter

Model	SK1290
Working area(mm)	1200*900mm
Laser tube power	40w, 60w, 80w,100w,130w,150w (optional)
laser tube type	Sealed CO2 laser tube/ or Reci laser tube, water-cooling, 10.6um
Working life of tube	1500hours for CO2 laser tube; 10000 hours for Reci laser tube
Max Engraving speed	0 - 60,000mm/min
Cutting speed	0- 30,000mm/min
Location precision	<0.01mm
Resetting positioning accuracy	0.01mm
Resolution ratio	<0.01mm
Laser tuber cooling	Water cooling
Power supply	AC 110 - 220V , 50 - 60Hz
Min. shaping聽 character	Chinese 2mm2mm,English 1mm1mm
Supported graphic	BMP, HPGL, PLT, DST, DXP, and AI
Driving system	Stepper motor
360掳 slope engrave	Yes
Cooling system	Water-cooling and protection system
Operating system	Windows98/ME/2000/XP/VISTA/2007
